型号Type
|
额定绝缘电压(V)
Rated insulation voltage |
机械寿命(×106)
Mechanical endurance |
电寿命(×106)
electric endurance |
额定工作电流(380V)(A)
Rated operational current(380V) |
可控电机功率（KW） |
|||||||
|
AC-3
|
AC-4
|
|||||||||||
|
AC-3
|
AC-4
|
AC-3
|
AC-4
|
230/ 220V
|
400/380V
|
500V
|
690/660V
|
400/380V
|
690/660V
|
|||
|
3TB-9/Z
|
660
|
10
|
1.0
|
0.2
|
9
|
3.3
|
2.4
|
4
|
5.5
|
5.5
|
1.4
|
2.4
|
|
3TB-12/Z
|
660
|
10
|
1.0
|
0.2
|
12
|
4.3
|
3.3
|
5.5
|
7.5
|
7.5
|
1.9
|
3.3
|
|
3TB-16/Z
|
660
|
10
|
1.0
|
0.2
|
16
|
7.7
|
4
|
7.5
|
10
|
10
|
3.5
|
6
|
|
3TB-22/Z
|
660
|
10
|
1.0
|
0.2
|
22
|
8.5
|
6.1
|
11
|
11
|
11
|
4
|
6.6
|
|
3TB-32/Z
|
660
|
10
|
1.0
|
0.2
|
32
|
15.6
|
8.5
|
15
|
21
|
23
|
7.5
|
13
|
|
吸引线圈工作电压范围
Coil voltage lolerance |
吸引线圈工作
电压范围 Coil voltage lolerance |
操作频率
(1/h)Switchina frequency |
约定发热电流
(A) Convention althermal current |
辅助触头额定工作电流(A) ㏑ated operational
current of auxiliary contacts |
辅助触头约
定发热电流(A) Conventional thermal current of auxiliary contacts |
辅助触头约定
绝缘电压(A) Conventional insulation voltage of auxilary contacts |
重量
Weight |
||||||
|
交流AC(50Hz)
|
直流DC
|
||||||||||||
|
保持（VA）closed
|
功率因数p.f.
|
吸合(VA)
/Closing |
功率因数P.f.
|
吸合和保持(W)Closed
&closing |
AC-3
|
AC-4
|
AC-15
|
DC-13
|
|||||
|
380/220V
|
110/220V
|
||||||||||||
|
10
|
0.29
|
68
|
0.82
|
6.2
|
0.8～1.1Us
|
1000
|
250
|
20
|
6/10
|
10
|
660
|
0.43
|
|
|
10
|
0.29
|
68
|
0.82
|
6.2
|
0.8～1.1Us
|
1000
|
250
|
20
|
6/10
|
10
|
660
|
0.43
|
|
|
10
|
0.29
|
68
|
0.82
|
6.2
|
0.8～1.1Us
|
750
|
250
|
30
|
6/10
|
10
|
660
|
0.49
|
|
|
10
|
0.29
|
68
|
0.82
|
6.2
|
0.8～1.1Us
|
750
|
250
|
30
|
6/10
|
10
|
660
|
0.49
|
|
|
10
|
0.29
|
68
|
0.82
|
6.2
|
0.8～1.1Us
|
750
|
250
|
55
|
4/6
|
10
|
660
|
0.7
|
|
|
型号Type
|
MAX
|
MAX
|
MAX
|
a
|
b
|
|
3TB-9Z-12Z/10 01 11 22
|
46
|
79
|
123
|
35±0.50
|
60±0.60
|
|
3TB-9Z-12Z/10 01 11 22
|
46
|
79
|
142
|
35±0.50
|
60±0.60
|
|
3TB-16Z-12Z/22
|
46
|
89
|
148
|
35±0.50
|
75±0.60
|
|
3TB-32Z-12Z/22 |
74
|
90
|
148
|
50±0.50
|
75±0.60
|
